You must be familiar with this one motorcycle, ducati monster, this bike has become a legend throughout the world. This ducati monste
Model:
Ducati Monster 696
Year:
2009
Category: Naked bike
Rating: 81.2 out of 100. Show full rating and compare with other bikes
Safety: See our safety campaign with the high safety rated bikes in this category.
Engine and transmission
Displacement: 696.00 ccm (42.47 cubic inches)
Engine type: V2
Stroke: 4
Power: 78.85 HP (57.6 kW)) @ 9000 RPM
Torque: 50.60 Nm (5.2 kgf-m or 37.3 ft.lbs)
Compression: 10.7:1
Bore x stroke: 88.0 x 57.2 mm (3.5 x 2.3 inches)
Fuel system: Injection. Siemens electronic fuel injection, 45mm throttle body
Valves per cylinder: 2
Fuel control: Desmodromic valve control
Starter: Electric
Cooling system: Air
Gearbox: 6-speed
Transmission type final drive: Chain
Clutch: APTC wet multiplate with hydraulic control
Physical measures
Dry weight: 161.0 kg (354.9 pounds)
Seat height: 770 mm (30.3 inches) If adjustable, lowest setting.
Wheelbase: 1,450 mm (57.1 inches)
Chassis and dimensions
Frame type: Tubular steel trellis frame
Rake (fork angle): 24.0°
Front suspension: Showa 43mm upside-down forks
Front suspension travel: 120 mm (4.7 inches)
Rear suspension: Progressive linkage with preload and rebound Sachs adjustable monoshock
Rear suspension travel: 148 mm (5.8 inches)
Front tyre dimensions: 120/60-ZR17
Rear tyre dimensions: 160/60-ZR17
Front brakes: Double disc
Front brakes diameter: 320 mm (12.6 inches)
Rear brakes: Single disc
Rear brakes diameter: 245 mm (9.6 inches)
Exhaust system: 2 aluminium mufflers
Speed and acceleration
Power/weight ratio: 0.4898 HP/kg
Other specifications
Fuel capacity: 15.00 litres (3.96 gallons)
Color options: Red (red/black), Matte Black (black/black), White (black/black)
